Dongguan Dkan Intelligent Equipment Co., Ltd. is a premier, high-tech global enterprise specializing in the R&D, manufacture, sales, and service of high-precision CNC machines. Operating under our internationally registered brand DKAN, we stand out among elite CNC machine manufacturers in China by providing advanced turning, milling, and intelligent multi-tasking manufacturing solutions!
With deep industry expertise, DKAN delivers a comprehensive product lineup, including high-rigidity slant-bed CNC lathes, vertical machining centers (VMCs), and high-efficiency turn-mill complex machines!
Adhering to our core market positioning of “High Speed, High Precision, and High Stability, ” we leverage both technological innovation and scalable production to optimize manufacturing processes!
We are dedicated to empowering global workshops-from automotive to aerospace sectors-with robust, automated solutions that maximize production value, enhance accuracy, and reduce operational costs through engineering excellence!
Workbench
| Workbench | Distance from table to spindle end | Min. 145mm, Max. 495mm |
| Table travel | 700*420mm | |
| Max. loading capacity | 300KG | |
| Pneumatic pressure | 6kgf/㎠ | |
| Spindle | Spindle speed | Max. 20000rpm |
| Spindle motor | 5.5kw servo motor | |
| Spindle type | Mechanical spindle | |
| Shank type | BT30 | |
| ACT content | 21 pcs | |
| Repeated positioning accuracy | ±0.01mm | |
| Surface engraving accuracy | ±0.02mm | |
| Travel | X axis travel | 500 mm |
| Y-axis travel | 800 mm | |
| Z axis travel | 300 mm | |
| Feed | X axis rapid speed | 48m/min |
| Y axis rapid speed | 48m/min | |
| Z axis rapid speed | 48m/min | |
| Cutting feed speed | 1-10000 mm/min | |
| Repeated positioning accuracy | ±0.005mm | |
| X / Y / Z axis positioning accuracy | ±0.005mm | |
| Size | Dimensions(L*W*H) | 1700*2000*2500mm |
| Weight | 3200KGS |
| Machine specification | ||
|---|---|---|
| Component Specification |
Controller | LNC / HNC |
| Ball screw | Taiwan P grade, 32mm diameter | |
| Guide rail | Taiwan C3 grade, 30mm diameter | |
| Spindle | Self- developed by Yashu | |
| Feed axis servo motor | ZONCN / HNC | |
| Spindle servo motor | ZONCN / HNC | |
| Tool magazine | 21pcs BT30 | |
